The BIXOLON SPP-L410IK5/BEG is a compact, rugged 4-inch mobile label printer for shipping labels, delivery notes, shelf labels and tickets on the move. It prints 203 dpi direct thermal labels up to 104 mm wide at up to 102 mm/s, runs ZPL II- and CPCL-based label formats unchanged thanks to its BPL-Z™ and BPL-C™ emulations, and weighs only 530 g with IP54 sealing and a 1.8 m drop rating. This version connects via Bluetooth (Classic + LE, Apple MFi certified for iPhone and iPad) with NFC tap-to-pair, plus USB and RS-232. Battery, charger with EU power cord and belt clip are in the box.
📦 What's in the box – SPP-L410IK5/BEG
- ✅ Printer – BIXOLON SPP-L410 – Bluetooth (MFi) + USB + RS-232
- ✅ Battery – Li-ion 7.2 V, 3200 mAh – rechargeable and removable
- ✅ Power supply / battery charger – charges the battery inside the printer (spare unit: PBC-1000)
- ✅ Power cord – EU plug, C7 connector
- ✅ Belt clip – for hands-free carrying on your belt
- ❌ USB cable – NOT included – PIC-R300U/STD (only needed for a wired connection)
- ❌ Serial (RS-232) cable – NOT included – PIC-R300S/STD (only needed for a wired connection)
- ❌ Labels – NOT included – no starter roll – order matching labels separately
- ❌ Case – Optional – PLC-R410/STD
- ℹ️ Drivers, SDKs & manuals – free download from BIXOLON (Windows, iOS, Android, mPrint app)
💡 Ready to print wirelessly: pair the printer via Bluetooth (or NFC tap-to-pair) straight out of the box. For a wired connection, add the BIXOLON USB cable PIC-R300U/STD or the BIXOLON RS-232 cable PIC-R300S/STD.
💡 Useful extras: a single battery cradle (BIXOLON PBD-R300/STD) or the BIXOLON PQC-R300/STD quad battery charger for spare batteries; the BIXOLON PUC-1000/STD USB power supply; the BIXOLON PCC-1000/STD vehicle charger for charging on the road; the BIXOLON PLC-R410/STD case; a vehicle holder (BIXOLON PVH-R410R/STD or BIXOLON PVH-R410P1/STD); matching labels (Zebra 3012913-T (101.6 × 152.4 mm), TSC 38-T102102-14LF (102 × 102 mm), Zebra 3012912-T (101.6 × 50.8 mm)).
Key Features
- 4-inch labels on the go – 112 mm media (105 mm or 80 mm with a partition), 104 mm print width, 203 dpi, rolls up to 56 mm on a 19 mm core.
- Drop-in compatible with your label formats – BPL-Z™ (ZPL II), BPL-C™ (CPCL) and SLCS emulations, so existing Zebra-style templates print without rework.
- Smallest in its class – 143 × 138 × 66 mm and 530 g including battery, with an ergonomic body that is easy to carry all day.
- Built for the field – IP54 water and dust resistance, 1.8 m drop rating and an operating range of −15 °C to +50 °C.
- Reliable media handling – fixed transmissive gap and black-mark sensors, paper-end and cover-open detection, easy drop-in paper loading.
- Fast and easy connection – Easy Bluetooth Pairing™ via the embedded NFC tag and smart Wi-Fi setup from a mobile device on wireless versions; USB 2.0 and RS-232 on every model.
- Plenty of memory – 128 MB SDRAM and 256 MB Flash for fonts, graphics, formats and logos; Unicode (UTF-8 / UTF-16) and 23 code pages.
- Developer-friendly – SDKs for Android, iOS, Windows, Linux, Chrome, Xamarin and Cordova, Windows and CUPS drivers, OPOS/JPOS, SAP device driver, Label Artist™ Mobile and mPrint apps.
Ideal Applications
- Parcel and courier delivery – shipping and address labels at the door
- Warehouse picking, put-away, cross-docking and pallet labels
- Retail shelf-edge, price and markdown labels on the sales floor
- Ticketing and parking enforcement
- Healthcare – specimen, asset and medication labels at the point of care
All SPP-L410 Versions
The highlighted row is the version you are currently viewing.
| Part Number | Wireless | Linerless | |
|---|---|---|---|
| SPP-L410IK5/BEG (this version) | Bluetooth (MFi) | No | Viewing |
| SPP-L410iK5L | Bluetooth (MFi) | Yes | View product |
| SPP-L410WK5 | Dual-band Wi-Fi | No | View product |
| SPP-L410WK5L | Dual-band Wi-Fi | Yes | View product |
| SPP-L410K5 | None (wired only) | No | View product |
| SPP-L410K5L/BEG | None (wired only) | Yes | View product |
Technical Specifications
| Part Number | SPP-L410IK5/BEG |
|---|---|
| Model | BIXOLON SPP-L410 |
| Printer Type | 4-inch mobile direct thermal label printer |
| Print Method | Direct thermal |
| Resolution | 203 dpi (8 dots/mm) |
| Print Speed | Up to 102 mm/s (4 ips) |
| Max. Print Width | 104 mm |
| Media Width | 112 mm (optional partitions: 105 mm / 80 mm) |
| Roll Diameter | Max. 56 mm |
| Core Size | 19 mm (0.75") |
| Media Thickness | 0.07–0.19 mm |
| Media Type | Die-cut (gap) labels, black-mark labels and tags, continuous direct thermal media |
| Sensors | Paper end, gap, black mark (fixed transmissive), paper cover open |
| Interfaces | USB 2.0 + RS-232 serial (combined 14-pin port) |
| Wireless | Bluetooth (Classic + LE), Apple MFi certified; Easy Bluetooth Pairing via NFC |
| Memory | 128 MB SDRAM, 256 MB Flash (optional 256 MB SDRAM / 512 MB Flash) |
| Printer Languages | SLCS, BPL-Z (ZPL II compatible), BPL-C (CPCL compatible) |
| Fonts / Character Sets | Bitmap fonts (10 SLCS, 16 BPL-Z, 7 BPL-C), scalable fonts (1 SLCS, 1 BPL-Z), 23 code pages, Unicode (UTF-8, UTF-16LE/BE); user-defined fonts, graphics, formats and logos |
| Barcodes | 1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-8, EAN-13, Industrial 2 of 5, Interleaved 2 of 5, LOGMARS, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2 of 5, UPC-A, UPC-E, UPC/EAN extensions, IMB; 2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code, TLC 39 |
| Drivers & Software | Windows driver (Europlus / Seagull), Linux / Mac CUPS driver, virtual COM USB driver, OPOS/JPOS, SAP device driver, Label Artist-II, BarTender UL, Network Auto Installer; SDKs for Android, iOS, Windows, Linux, Chrome, Xamarin, Cordova; Label Artist Mobile and mPrint apps |
| Mobile Printing | iOS (MFi), Android and Windows smartphones, tablets and handheld computers |
| Battery | Li-ion 7.2 V, 3200 mAh (current BIXOLON spec; earlier production: 7.3 V, 2850 mAh), removable; charging time under 4 h |
| Charging | In the printer with the supplied AC/DC charger; optional USB power supply PUC-1000/STD, vehicle charger PCC-1000/STD, single battery cradle PBD-R300/STD, quad battery charger PQC-R300/STD |
| Dimensions (W × D × H) | 143 × 138 × 66 mm (W × D × H) |
| Weight | 530 g including battery |
| Color | Black |
| Operating Temperature | −15 °C to 50 °C |
| Storage Temperature | −30 °C to 70 °C |
| Humidity | 10–80% RH |
| Environmental Sealing | IP54 |
| Drop Specification | 1.8 m (6 ft) |
| Certifications | Energy Star (charger), Apple MFi |
| Warranty | 24 months |
| In the Box | BIXOLON SPP-L410 printer (Bluetooth (MFi, NFC pairing) + USB + RS-232), Li-ion battery 7.2 V 3200 mAh (current BIXOLON spec; earlier units 2850 mAh), AC/DC battery charger with EU power cord (C7), belt clip – USB cable (PIC-R300U/STD) and RS-232 cable (PIC-R300S/STD) NOT included (only needed for a wired connection); labels not included |
Need receipts as well as labels? The BIXOLON SPP-R410 is the receipt-and-label model on the same 4-inch platform and uses the same batteries, chargers, cases and vehicle holders. For BIXOLON's newer 4-inch generation, see the BIXOLON XM7-40; for 3-inch labels with an LCD and a built-in peeler, the BIXOLON SPP-L3000. Compare other models in our Mobile Label Printers collection or contact our team for volume pricing.
Available Versions
SPP-L410IK5/BEG
Selected
Wireless
Bluetooth
Linerless
No
label printer, mobile printer, direct thermal, resolution: 8 dots/mm (203 dpi), media width (max.): 112 mm, print width (max.): 104 mm, roll diameter (max.): 56 mm, speed (max.): 102 mm/s, USB, RS232, Bluetooth (BLE), Black Mark Sensor, Gap Sensor, emulation: ZPLII, SLCS, CPCL, RAM: 128 MB, Flash: 256 MB, incl.: power supply unit, power cable, belt clip, battery, 2850mAh
442,75 €In Stock
SPP-L410iK5L
Wireless
Bluetooth
Linerless
Yes
label printer, mobile printer, direct thermal, resolution: 8 dots/mm (203 dpi), media width (max.): 112 mm, print width (max.): 104 mm, roll diameter (max.): 56 mm, speed (max.): 76mm/sec., USB, RS232, Bluetooth (BLE), linerless platen, Black Mark Sensor, Gap Sensor, emulation: ZPLII, SLCS, CPCL, RAM: 128 MB, Flash: 256 MB, incl.: power supply unit, power cable, belt clip, battery, 2850mAh
SPP-L410K5
Wireless
None
Linerless
No
label printer, mobile printer, direct thermal, resolution: 8 dots/mm (203 dpi), media width (max.): 112 mm, print width (max.): 104 mm, roll diameter (max.): 56 mm, speed (max.): 102 mm/s, USB, RS232, Black Mark Sensor, Gap Sensor, emulation: ZPLII, SLCS, CPCL, RAM: 128 MB, Flash: 256 MB, incl.: power supply unit, power cable, belt clip, battery, 2850mAh
SPP-L410K5L/BEG
Wireless
None
Linerless
Yes
label printer, mobile printer, direct thermal, resolution: 8 dots/mm (203 dpi), media width (max.): 112 mm, print width (max.): 104 mm, roll diameter (max.): 56 mm, speed (max.): 76mm/sec., USB, RS232, linerless platen, Black Mark Sensor, Gap Sensor, emulation: ZPLII, SLCS, CPCL, RAM: 128 MB, Flash: 256 MB, incl.: power supply unit, power cable, belt clip, battery, 2850mAh
SPP-L410WK5
Wireless
Wi-Fi
Linerless
No
label printer, mobile printer, direct thermal, resolution: 8 dots/mm (203 dpi), media width (max.): 112 mm, print width (max.): 104 mm, roll diameter (max.): 56 mm, speed (max.): 102 mm/s, USB, RS232, Wi-Fi (802.11a/b/g/n), Black Mark Sensor, Gap Sensor, emulation: ZPLII, SLCS, CPCL, RAM: 128 MB, Flash: 256 MB, incl.: power supply unit, power cable, belt clip, battery, 2850mAh
SPP-L410WK5L
Wireless
Wi-Fi
Linerless
Yes
label printer, mobile printer, direct thermal, resolution: 8 dots/mm (203 dpi), media width (max.): 112 mm, print width (max.): 104 mm, roll diameter (max.): 56 mm, speed (max.): 76mm/sec., USB, RS232, Wi-Fi (802.11a/b/g/n), linerless platen, Black Mark Sensor, Gap Sensor, emulation: ZPLII, SLCS, CPCL, RAM: 128 MB, Flash: 256 MB, incl.: power supply unit, power cable, belt clip, battery, 2850mAh
