M3MOBILE Rugged handheld computer : SM15

M3 SM15 and M3 SM20 UHF(Ultra High Frequency) Tag reading Features

M3 Mobile SM15 X Terminal (S15X4C-O0CFSS-HF-R)

Name: M3 Mobile SM15 X Terminal (S15X4C-O0CFSS-HF-R)
Brand: M3
SKU: m3sm15x-44
Availability: InStock

834,01 € +VAT

Product variants

Mobile Broadband

4G LTE + GPSWi-Fi only

Operating System

Android 10 (GMS)Android 7.1 (GMS)Android 8.1 (AOSP)Android 8.1 (GMS)

Scanner Type

No scan engine (camera only)SE4710 standard range SE4750 mid range SE965 1D laser

Battery (mAh)

41006150

Memory

2 GB / 16 GB4 GB / 64 GB

Free Shipping over 250 €. Usually delivered within 3–5 working days.

0% VAT for EU/EEA companies (excl. Estonia). Enter a valid VAT number to automatically generate a 0% VAT invoice.

Available: In Stock
Vendor: M3
Type: Handheld Terminals
Barcode: S15X4C-O0CFSS-HF-R
Collections: Handheld Terminals , Mobile Terminals

📄 Download Product Brochure (PDF)

M3 Mobile SM15 X Terminal (S15X4C-O0CFSS-HF-R)

834,01 € +VAT

Description

Description

The M3 Mobile SM15X is a rugged full-touch Android mobile computer in a slim smartphone format – built for field sales, delivery, retail and warehouse staff who scan all day. It combines a 5" Corning Gorilla Glass touchscreen that works with gloves and wet fingers, an octa-core Qualcomm Snapdragon processor, NFC, a hot-swappable battery and IP65 sealing. This version, S15X4C-O0CFSS-HF-R, is the top model with 4G LTE (dual SIM), GPS, a 5" Full HD display, 2.2 GHz processor and front camera. Configuration: no dedicated scan engine (barcode reading via the camera only), 4 GB RAM / 64 GB Flash, Android 8.1 with GMS, standard 4100 mAh battery.

📦 What's in the box – S15X4C-O0CFSS-HF-R

✅ M3 Mobile SM15X – mobile computer, black, 5" Full HD, 4 GB / 64 GB
✅ Battery – standard 4100 mAh Li-ion, hot-swappable (SM15-BATT-S41)
✅ Google Mobile Services (GMS) – licensed and preinstalled – Google Play and Google apps ready to use
✅ Protective display film – fitted to the device
✅ Quick start guide – drivers, tools and user guides are a free download from M3 Mobile
❌ Charger / power supply – NOT included – the SM15X has no charging socket of its own – it charges in a charging cradle or with a snap-on charging adapter (see the options below)
❌ Charging cradle – NOT included
❌ Hand strap – NOT included
❌ SIM card – NOT included – 2 SIM slots (or 1 SIM + 1 SAM) for 4G LTE – SIM card / data plan from your mobile operator

⚠️ Please note: no charger, charging cable or cradle is included. To charge the SM15X, please order separately: the M3 SM15-2CRD-CC0 2-slot charging/USB cradle (terminal + spare battery) with the M3 SM15-PWSP-2EU power supply; the M3 SM15-2CRD-C00 (charging only) or M3 SM15-2CRD-EC0 (Ethernet) 2-slot cradle, also with the M3 SM15-PWSP-2EU power supply; or the M3 SM15-SNAP-C0A USB-C or M3 SM15-SNAP-C0U USB snap-on charging adapter with a 5 V USB power adapter (e.g. M3 SM10-PWSP-U00).

💡 Useful extras: a spare battery for hot-swapping (M3 SM15-BATT-S41); the M3 SM15-BATT-E61 extended 6150 mAh battery for longer shifts (needs the M3 SM10-BTDO-EHF extended battery cover); the M3 SM15-8CRD-C00 or M3 SM15-8CRD-E00 cradles for 4 terminals + 4 spare batteries (with the M3 SM15-PWSP-8EU power supply); a pistol grip – M3 SM10-TRIG-S00 or M3 SM15-TRIG-L00 with built-in long-range scanner; the M3 SM1X-BOOT-02 protective boot for extra drop protection; hand straps (M3 SM10-STRP-S10, pack of 10); a holster or fabric case (M3 UNIV-CASE-FSH or M3 UNIV-CASE-F00); the M3 SM15-SCPR screen protector; a vehicle cradle (M3 SM15-VCRD-C01 or M3 SM15-VCRD-C02) with RAM mount (M3 UNIV-RAMT or M3 UNIV-RAMS); a wearable kit for hands-free scanning (M3 SM15-WEWM-UA1, M3 SM15-WEWM-UB1 and M3 SM15-WETR-U00); UHF RFID reading with the M3 SM15-SNAP-UEB snap-on or the M3 SM15-TRIG-UEB RFID pistol grip; a service plan with fast repair and battery replacement (M3 SM15-SPST-XB3, M3 SM15-SPST-XB5 or M3 SM15-SPRE-X51).

Key Features

Smartphone format, rugged build – only 21.6 mm thin, IP65 dust and water protection, 1.2 m drops to concrete (1.8 m with protective boot) and 500 tumbles at 1 m with boot.
Top performance – 2.2 GHz Qualcomm Snapdragon 626 octa-core, 4 GB RAM / 64 GB flash, 5" Full HD display, 16 MP rear and 5 MP front camera, 4G LTE dual SIM and GPS.
Camera-based scanning – this version has no dedicated scan engine; barcodes can be read via the auto-focus camera with a scanning app – ideal where scanning is occasional.
5" Gorilla Glass touchscreen – sunlight-readable, Corning Gorilla Glass 3, works with gloves, wet fingers or a stylus; scan keys on both sides plus Home, Back, Menu and Enter keys.
4100 mAh battery with hot swap – light 280 g device, fast charging and battery replacement without switching off.
Enterprise connectivity – dual-band Wi-Fi 5 (802.11ac), Bluetooth 4.1 LE and NFC (ISO 14443 A/B, ISO 15693); UHF RFID via snap-on or pistol-grip reader.
Complete accessory system – 2-slot and 8-slot charging/Ethernet cradles, USB snap-on chargers, pistol grips (incl. long range), wearable wrist mount and belt sled, vehicle cradles and RAM mounts.

Ideal Applications

Field sales, order taking and route accounting
Parcel and courier delivery with proof of delivery
Retail stock checks, price checks and mobile POS
Warehouse picking, receiving and inventory
Field service and maintenance
Hands-free scanning with wrist mount or belt sled and ring trigger

All SM15 Versions

The highlighted row is the version you are currently viewing.

Part Number	Model	Connectivity	Scan Engine	Memory	Operating System	Battery
S15W0C-N2CHSS-HF	SM15W	Wi-Fi only	SE4710	2 GB / 16 GB	Android 7.1 GMS	Standard 4100 mAh	View product
S15W0C-N2CHSE-HF	SM15W	Wi-Fi only	SE4710	2 GB / 16 GB	Android 7.1 GMS	Extended 6150 mAh	View product
S15W0C-12CHSS-HF	SM15W	Wi-Fi only	SE4710	2 GB / 16 GB	Android 8.1 AOSP	Standard 4100 mAh	View product
S15W0C-12CHSE-HF	SM15W	Wi-Fi only	SE4710	2 GB / 16 GB	Android 8.1 AOSP	Extended 6150 mAh	View product
S15N4C-N2CHSS-HF	SM15N	4G LTE + GPS	SE4710	2 GB / 16 GB	Android 7.1 GMS	Standard 4100 mAh	View product
S15N4C-N2CHSE-HF	SM15N	4G LTE + GPS	SE4710	2 GB / 16 GB	Android 7.1 GMS	Extended 6150 mAh	View product
S15N4C-O0CHSE-HF	SM15N	4G LTE + GPS	camera only	2 GB / 16 GB	Android 8.1 GMS	Extended 6150 mAh	View product
S15N4C-O1CHSS-HF	SM15N	4G LTE + GPS	SE965 1D	2 GB / 16 GB	Android 8.1 GMS	Standard 4100 mAh	View product
S15N4C-O2CHSS-HF	SM15N	4G LTE + GPS	SE4710	2 GB / 16 GB	Android 8.1 GMS	Standard 4100 mAh	View product
S15N4C-O2CHSE-HF	SM15N	4G LTE + GPS	SE4710	2 GB / 16 GB	Android 8.1 GMS	Extended 6150 mAh	View product
S15N4C-Q1CHSS-HF	SM15N	4G LTE + GPS	SE965 1D	2 GB / 16 GB	Android 10 GMS	Standard 4100 mAh	View product
S15N4C-Q1CHSE-HF	SM15N	4G LTE + GPS	SE965 1D	2 GB / 16 GB	Android 10 GMS	Extended 6150 mAh	View product
S15N4C-Q2CHSS-HF	SM15N	4G LTE + GPS	SE4710	2 GB / 16 GB	Android 10 GMS	Standard 4100 mAh	View product
S15X4C-N2CFSE-HF-R	SM15X	4G LTE + GPS	SE4710	4 GB / 64 GB	Android 7.1 GMS	Extended 6150 mAh	View product
S15X4C-N3CFSE-HF-R	SM15X	4G LTE + GPS	SE4750	4 GB / 64 GB	Android 7.1 GMS	Extended 6150 mAh	View product
S15X4C-O0CFSS-HF-R (this version)	SM15X	4G LTE + GPS	camera only	4 GB / 64 GB	Android 8.1 GMS	Standard 4100 mAh	Viewing
S15X4C-O2CFSS-HF-R	SM15X	4G LTE + GPS	SE4710	4 GB / 64 GB	Android 8.1 GMS	Standard 4100 mAh	View product
S15X4C-O2CFSE-HF-R	SM15X	4G LTE + GPS	SE4710	4 GB / 64 GB	Android 8.1 GMS	Extended 6150 mAh	View product
S15X4C-O2CFSS-HF-STR	SM15X	4G LTE + GPS	SE4750	4 GB / 64 GB	Android 8.1 GMS	Standard 4100 mAh	View product
S15X4C-O2CFSE-HF-STR	SM15X	4G LTE + GPS	SE4750	4 GB / 64 GB	Android 8.1 GMS	Extended 6150 mAh	View product
S15X4C-Q1CFSS-HF	SM15X	4G LTE + GPS	SE965 1D	4 GB / 64 GB	Android 10 GMS	Standard 4100 mAh	View product
S15X4C-Q1CFSE-HF	SM15X	4G LTE + GPS	SE965 1D	4 GB / 64 GB	Android 10 GMS	Extended 6150 mAh	View product
S15X4C-Q2CFSS-HF	SM15X	4G LTE + GPS	SE4710	4 GB / 64 GB	Android 10 GMS	Standard 4100 mAh	View product
S15X4C-Q2CFSE-HF	SM15X	4G LTE + GPS	SE4710	4 GB / 64 GB	Android 10 GMS	Extended 6150 mAh	View product
S15X4C-Q3CFSS-HF	SM15X	4G LTE + GPS	SE4750	4 GB / 64 GB	Android 10 GMS	Standard 4100 mAh	View product
S15X4C-Q3CFSE-HF	SM15X	4G LTE + GPS	SE4750	4 GB / 64 GB	Android 10 GMS	Extended 6150 mAh	View product

Technical Specifications

Part Number	S15X4C-O0CFSS-HF-R
Model	M3 Mobile SM15X – top model with 4G LTE and Full HD display of the SM15 full-touch series
Operating System	Android 8.1 (Oreo) with Google Mobile Services (GMS)
Processor	Qualcomm Snapdragon 626, octa-core 2.2 GHz
Memory (RAM / Flash)	4 GB RAM / 64 GB Flash
Expansion	microSD slot
Display	5" Full HD (1920 × 1080), outdoor-viewable, Corning Gorilla Glass 3
Touch Panel	Capacitive – finger, glove, wet operation and pen
Buttons	Power, volume +/–, camera key, 2 side scan keys (left/right), 4 front keys (Home, Back, Menu, Enter/Scan)
Scan Engine	None – barcode reading via the camera with a scanning app
Rear Camera	16 MP auto-focus
Front Camera	5 MP auto-focus
Wi-Fi	Wi-Fi 5 – IEEE 802.11 a/b/g/n/ac, dual-band
Bluetooth	Bluetooth 4.1 LE, Class II
NFC	HF 13.56 MHz – ISO 14443 A/B, ISO 15693
RFID	UHF (EPC C1 Gen2, ISO 18000-6C) optional via SM15-SNAP-UEB snap-on or SM15-TRIG-UEB pistol grip
Mobile Data (WWAN)	4G LTE FDD 800/850/900/1800/2100/2600 MHz; UMTS/HSPA+ 850/900/2100 MHz; GSM/GPRS/EDGE 850/900/1800 MHz
SIM	2 SIM or 1 SIM + 1 SAM
GPS/GNSS	A-GPS, GLONASS, BeiDou
Voice & Audio	Speaker, microphone, vibration; Bluetooth headset support; voice calls via 4G
Ports	Micro-USB docking connector – used via a USB snap-on or charging cradle (no separate charging socket)
Sensors	Gyroscope, proximity sensor, light sensor
Battery	Standard 4100 mAh / 3.8 V Li-ion (SM15-BATT-S41); fast charging; hot-swappable
Charging	In a charging cradle (e.g. SM15-2CRD-CC0 with SM15-PWSP-2EU) or with a USB snap-on charging adapter – not included
Form Factor	Full-touch rugged mobile computer (smartphone format)
Dimensions	76.4 × 154.8 × 21.6 mm (W × H × D)
Weight	280 g (with standard battery)
Drop Spec	1.2 m to concrete (1.8 m with protective boot)
Tumble Spec	1,000 tumbles at 0.5 m; 500 tumbles at 1 m (with boot)
Sealing	IP65
Operating Temperature	−20 °C to 60 °C
Storage Temperature	−30 °C to 80 °C
Humidity	0–95% non-condensing
Colour	Black
Warranty	12 months (M3 Mobile 1-year hardware warranty); 3- and 5-year M3 service packages available
In the Box	M3 Mobile SM15X mobile computer (S15X4C-O0CFSS-HF-R), standard 4100 mAh Li-ion battery (SM15-BATT-S41), Google Mobile Services (GMS) licence preinstalled, protective display film (factory-fitted), quick start guide – charging cradle / snap-on charger, power supply, hand strap and SIM card NOT included (order separately)

The SM15 series comprises the SM15W (Wi-Fi), the SM15N (4G LTE, HD display) and the top model SM15X (4G LTE, Full HD, 4 GB RAM). A more affordable 4G version with HD display is the M3 Mobile SM15N (S15N4C-O0CHSE-HF). Working only within Wi-Fi coverage? The M3 Mobile SM15W (S15W0C-12CHSS-HF) is the Wi-Fi model. M3 Mobile's current full-touch model is the M3 Mobile SM20. Compare all models in our Handheld Terminals collection, or contact our team for volume pricing, staging and MDM set-up.
