The Datalogic QuickScan QD2200 (corded model QD2220) is a lightweight 1D linear imager for fast, reliable barcode scanning at the checkout and service desk. Its extra-wide scan angle and long, sharp scan line read wide and poorly printed 1D barcodes from close up to more than 1 m away, and every good read is confirmed by Datalogic's Green Spot. It comes with a 5-year Datalogic warranty. This version, QD2220-BKK1, is supplied with a 2 m USB cable, ready to plug in and scan.
📦 What's in the box – QD2220-BKK1
- ✅ Datalogic QuickScan QD2220 scanner – Black
- ✅ USB cable – Type A, straight, 2 m, Datalogic 90A052065
- ❌ Stand – not included
💡 Want hands-free scanning? Add the Datalogic stand STD-QW25-BK or the Datalogic Autosense stand STD-AUTO-QD25-BK to your order. The scanner switches to hands-free mode automatically when placed in the stand.
Key Features
- 1D linear imager – reads all standard 1D barcodes, including GS1 DataBar. Please note: it does not read 2D codes such as QR codes or Data Matrix; for those, choose a 2D model such as the Datalogic QuickScan QD2500.
- Extra-wide scan angle and long scan line – a 56° field of view captures wide barcodes without moving back from the item.
- Extended reading range – from close contact up to 68 cm on 13 mil EAN/UPC and 103 cm on 20 mil Code 39, down to 3 mil resolution.
- Fast and forgiving – up to 400 scans per second, 40 IPS motion tolerance and reading down to 15% print contrast.
- Datalogic Green Spot – a green light projected onto the barcode confirms every good read, even in noisy environments.
- Simple USB connection – plug and play via USB (USB-C cable available); easy setup with the free Datalogic Aladdin tool and OPOS/JavaPOS utilities.
- Built to last – lightweight 123 g design that withstands repeated 1.5 m drops to concrete, IP42 sealed, with a 5-year (60-month) Datalogic warranty.
Ideal Applications
- Retail point of sale – check-out, loyalty cards and paper coupons
- Commercial services – postal, banking, public administration, utilities and laboratories
- Hospitality and transport – ticketing for events, concerts and travel
- Government lottery and gaming
All QuickScan QD2200 Versions
The highlighted row is the version you are currently viewing.
| Part Number | Cable | Stand | |
|---|---|---|---|
| QD2220-BK | ❌ Not included | — | View product |
| QD2220-BKK1 (this version) | USB, straight 2 m | — | Viewing |
| QD2220-BKK1S | USB, straight 2 m | ✅ Yes | View product |
Technical Specifications
| Part Number | QD2220-BKK1 |
|---|---|
| Model | Datalogic QuickScan QD2220 (QD2200 series) |
| Scanner Type | Corded handheld 1D linear imager (does not read 2D codes) |
| Image Sensor | CCD solid-state linear sensor |
| Light Source | 617 nm red LED |
| Field of View | 56° ± 2° |
| Depth of Field (typical) | Code 39 4 mil: 2.5–22 cm; Code 39 5 mil: 2–30 cm; Code 39 7.5 mil: 1–45 cm; Code 39 10 mil: 1–60 cm; Code 39 20 mil: 3–103 cm; EAN/UPC 13 mil: 1–68 cm |
| Maximum Resolution | 3 mil (0.077 mm) |
| Scan Rate | Up to 400 scans/s |
| Motion Tolerance | 40 IPS (102 cm/s) |
| Minimum Print Contrast | 15% |
| Reading Angles | Pitch ±65°, roll ±45°, skew ±65° |
| Symbologies | All standard 1D codes incl. GS1 DataBar linear codes (auto-discrimination) |
| Host Interfaces | USB (USB-C cable available) |
| Reading Indicators | Datalogic Green Spot, good-read LED, beeper (adjustable tone) |
| Color | Black |
| Dimensions | 15.6 × 6.7 × 10.7 cm |
| Weight | 123 g |
| Input Voltage | 5 VDC ± 5% |
| Current Draw | Operating: < 165 mA; standby: < 40 mA (at 5 V) |
| Environmental Sealing | IP42 |
| Drop Resistance | Repeated 1.5 m drops to concrete |
| Electrostatic Discharge | 16 kV (air discharge) |
| Ambient Light Immunity | 0–120,000 lux |
| Trigger Life | 3 million actuations |
| Operating Temperature | 0 °C to 50 °C |
| Storage Temperature | −40 °C to 70 °C |
| Humidity | 0–95% RH, non-condensing |
| Software & Management | Datalogic Aladdin configuration tool, OPOS / JavaPOS utilities, remote host download |
| Warranty | 60 months |
| In the Box | QuickScan QD2220 scanner, USB cable (Type A, straight, 2 m, 90A052065) |
Not sure which version you need? If you already have a compatible Datalogic USB cable, the scanner-only version is the most economical choice; for a new workstation, pick the USB kit – with the stand if you also want hands-free scanning. Need to read QR codes or codes on phone screens? Choose a 2D scanner instead. Compare other models in our Handheld Barcode Scanners collection or contact our team for volume pricing.
Available Versions
QD2220-BK
1D linear imager, USB
Interface cable not included
handheld scanner, 1D, imager, miscellaneous (properties/characteristics), interfaces, connection: USB, optional accessories, order separately: interface cable, protection class, IP42, colour, colour: black
QD2220-BKK1
Selected
1D linear imager, USB
Includes: USB cable (2 m)
handheld scanner, 1D, imager, miscellaneous (properties/characteristics), interfaces, connection: USB, accessories, incl.: cable (USB, 2 m, straight), protection class, IP42, colour, colour: black
45,30 €In Stock
QD2220-BKK1S
1D linear imager, USB
Includes: USB cable (2 m), stand
handheld scanner, 1D, imager, miscellaneous (properties/characteristics), interfaces, connection: USB, accessories, incl.: cable (USB, 2 m, straight), stand, protection class, IP42, colour, colour: black
