The TSC DH220LHC (DH220LHC-A001-1222) is a 2-inch healthcare desktop label printer for direct-thermal printing at 203 dpi and up to 203 mm/s (8 ips), with a max. print width of 54 mm. Its white, antibacterial and disinfectant-ready housing with sealed buttons and an IEC 60601-1 medical-grade power supply suit hospitals, laboratories and pharmacies. This LED version keeps operation simple with status icons and feed, pause and reprint buttons. A factory-fitted guillotine cutter cuts labels and wristbands to length. It holds large label rolls up to 165 mm (6.5") OD, handles labels, tags and patient wristbands 10–60 mm wide, speaks TSPL-EZD with automatic EPL, ZPL and DPL emulation and connects via USB 2.0, RS-232, 10/100 Ethernet and USB host, plus factory-installed MFi Bluetooth for iOS and Android. Supplied with power supply, EU power cord and USB cable – ready to print.
📦 What's in the box – DH220LHC-A001-1222
- ✅ TSC DH220LHC label printer – 203 dpi, 2" (54 mm), USB 2.0 + RS-232 + Ethernet + USB host, MFi Bluetooth
- ✅ Guillotine cutter (factory-fitted) – full and partial cut for labels and tags
- ✅ Power supply – IEC 60601-1 medical-grade power supply, 100–240 V AC → 24 V DC, 60 W
- ✅ Power cord – EU plug (Schuko)
- ✅ USB cable – USB 2.0 A-to-B – connect and print straight away
- ✅ Drivers & software – Windows driver, TSC Console and labeling software – free download from TSC
- ✅ Setup guide
- ❌ Labels / wristbands – NOT included – order labels to suit your application (see compatible labels below)
- ❌ Ethernet (LAN) cable – NOT included – use any standard RJ45 patch cable
✅ Ready to print: power supply, power cord and USB cable are in the box – you only need labels or wristbands (direct thermal – no ribbon required).
💡 Useful extras: the TSC CUT-DH220-0001 linerless cutter kit or the TSC TEAR-DH220-0001 linerless tear-off kit to print liner-free labels; the TSC OP-COM-0002 external roll mount for large rolls on 3" cores.
Key Features
- Direct thermal at 203 dpi – up to 203 mm/s (8 ips), max. print width 54 mm, labels up to 25.4 m long
- Healthcare design: white antibacterial, disinfectant-ready enclosure with an easy-to-clean surface and sealed buttons
- IEC 60601-1 certified medical-grade power supply for safe use in clinical environments
- Large 165 mm (6.5") label rolls on 25.4–38.1 mm cores, media 10–60 mm wide: die-cut, continuous, black-mark, fanfold and notched labels, tags and patient wristbands
- LED status and icon indicators with feed, pause and reprint buttons – nothing to configure
- Factory-fitted guillotine cutter (full and partial cut) for labels, tags and wristbands
- TSPL-EZD firmware with automatic EPL, ZPL/ZPL II and DPL language switching – existing label templates print unchanged
- USB 2.0, RS-232, 10/100 Ethernet and USB host plus factory-installed MFi Bluetooth for printing from iOS and Android devices
- 256 MB SDRAM, 512 MB Flash, microSD slot (up to 512 GB), real-time clock and buzzer
- Remote management via embedded web page, TSC Console and SOTI Connect; HTTPS, SNMPv3 and 802.1X security
- 3-year TSC printer warranty in EMEA
Ideal Applications
- Hospitals – patient ID wristbands, admission and chart labels
- Laboratories – specimen and sample tube labels
- Pharmacies – medication and prescription labels
- Blood banks and sterile services – traceability labels
- Clinics, care homes and veterinary practices – sample, medication and file labels
All DH220LHC Versions
The highlighted row is the version you are currently viewing.
| Part Number | Display | Media Option | Linerless | Wireless | |
|---|---|---|---|---|---|
| DH220LHC-A001-0002 | 3.5" touch LCD | Tear-off | No | — | View product |
| DH220LHC-A001-0012 | 3.5" touch LCD | Peeler | No | — | View product |
| DH220LHC-A001-0022 | 3.5" touch LCD | Cutter | No | — | View product |
| DH220LHC-A001-0032 | 3.5" touch LCD | Cutter | Yes | — | View product |
| DH220LHC-A001-0042 | 3.5" touch LCD | Tear-off | Yes | — | View product |
| DH220LHC-A001-0102 | 3.5" touch LCD | Tear-off | No | Wi-Fi + Bluetooth | View product |
| DH220LHC-A001-0112 | 3.5" touch LCD | Peeler | No | Wi-Fi + Bluetooth | View product |
| DH220LHC-A001-0122 | 3.5" touch LCD | Cutter | No | Wi-Fi + Bluetooth | View product |
| DH220LHC-A001-0132 | 3.5" touch LCD | Cutter | Yes | Wi-Fi + Bluetooth | View product |
| DH220LHC-A001-0142 | 3.5" touch LCD | Tear-off | Yes | Wi-Fi + Bluetooth | View product |
| DH220LHC-A001-0202 | 3.5" touch LCD | Tear-off | No | Bluetooth (MFi) | View product |
| DH220LHC-A001-0212 | 3.5" touch LCD | Peeler | No | Bluetooth (MFi) | View product |
| DH220LHC-A001-0222 | 3.5" touch LCD | Cutter | No | Bluetooth (MFi) | View product |
| DH220LHC-A001-0232 | 3.5" touch LCD | Cutter | Yes | Bluetooth (MFi) | View product |
| DH220LHC-A001-0242 | 3.5" touch LCD | Tear-off | Yes | Bluetooth (MFi) | View product |
| DH220LHC-A001-1002 | LED (no display) | Tear-off | No | — | View product |
| DH220LHC-A001-1012 | LED (no display) | Peeler | No | — | View product |
| DH220LHC-A001-1022 | LED (no display) | Cutter | No | — | View product |
| DH220LHC-A001-1032 | LED (no display) | Cutter | Yes | — | View product |
| DH220LHC-A001-1042 | LED (no display) | Tear-off | Yes | — | View product |
| DH220LHC-A001-1102 | LED (no display) | Tear-off | No | Wi-Fi + Bluetooth | View product |
| DH220LHC-A001-1112 | LED (no display) | Peeler | No | Wi-Fi + Bluetooth | View product |
| DH220LHC-A001-1122 | LED (no display) | Cutter | No | Wi-Fi + Bluetooth | View product |
| DH220LHC-A001-1132 | LED (no display) | Cutter | Yes | Wi-Fi + Bluetooth | View product |
| DH220LHC-A001-1142 | LED (no display) | Tear-off | Yes | Wi-Fi + Bluetooth | View product |
| DH220LHC-A001-1202 | LED (no display) | Tear-off | No | Bluetooth (MFi) | View product |
| DH220LHC-A001-1212 | LED (no display) | Peeler | No | Bluetooth (MFi) | View product |
| DH220LHC-A001-1222 (this version) | LED (no display) | Cutter | No | Bluetooth (MFi) | Viewing |
| DH220LHC-A001-1232 | LED (no display) | Cutter | Yes | Bluetooth (MFi) | View product |
| DH220LHC-A001-1242 | LED (no display) | Tear-off | Yes | Bluetooth (MFi) | View product |
Technical Specifications
| Part Number | DH220LHC-A001-1222 |
|---|---|
| Model | TSC DH220LHC (DH220L Series for Healthcare, 2-inch) |
| Printer Type | 2-inch direct thermal desktop label printer for healthcare |
| Print Method | Direct thermal |
| Resolution | 203 dpi (8 dots/mm) |
| Print Speed | Up to 203 mm/s (8 ips) |
| Max Print Width | 54 mm (2.13") |
| Max Print Length | 25,400 mm (1,000") |
| Media Width | 10–60 mm (0.39"–2.36") |
| Media Thickness | 0.06–0.19 mm (2.36–7.48 mil) |
| Roll Diameter | 165 mm (6.5") OD |
| Core Size | 25.4–38.1 mm (1"–1.5") |
| Media Types | Continuous, die-cut, black mark, fanfold, notched (outside wound), tags and patient wristbands; label length 5 mm – 25,400 mm |
| Sensors | Transmissive gap sensor, reflective black-mark sensor (position adjustable), head-open sensor |
| Interfaces | USB 2.0, RS-232 serial, internal Ethernet 10/100 Mbps, USB host; microSD card slot |
| Wireless | MFi Bluetooth (factory-installed, for iOS and Android) |
| Processor | 32-bit RISC CPU |
| Memory | 256 MB SDRAM, 512 MB Flash; microSD expansion up to 512 GB (FAT32/exFAT) |
| Real-Time Clock | Standard (plus buzzer) |
| Printer Languages | TSPL-EZD with automatic EPL, ZPL, ZPL II and DPL language switching |
| Fonts / Character Sets | 8 alphanumeric bitmap fonts; Monotype true-type engine with CG Triumvirate Bold Condensed; ARIALUNI.TTF Unicode font (UTF-8); 0/90/180/270° rotation |
| Barcodes | 1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN/UPC add-on, MSI, Plessey, Postnet, China Post, ITF-14, EAN-14, Code 11, Telepen, Planet, Code 49, Deutsche Post Identcode/Leitcode, LOGMARS; 2D: TLC39, Codablock F, PDF417, MicroPDF417, MaxiCode, DataMatrix, QR Code, Aztec, GS1 DataBar |
| Display | No display – LED status and icon indicators; power, feed, pause and reprint buttons |
| Media Options | Guillotine cutter, full and partial cut (factory-fitted) |
| Options | Guillotine cutter, peel-off module, linerless cutter kit, linerless tear-off kit, Wi-Fi + Bluetooth 5.0 combo module, HF RFID tear-off upgrade kit, external label roll mount, KP-200 Plus keyboard, 10 mm narrow media adaptor |
| Management & Security | Internal embedded web page, virtual control panel, TSC Console, SOTI Connect (licence); HTTPS, SNMPv3, 802.1X, TCP/IP port 9100 filter; TPH Care printhead diagnostics |
| Enclosure | Double-walled clamshell; disinfectant-ready, antibacterial white plastic with easy-to-clean surface and sealed buttons |
| Power Supply | IEC 60601-1 certified universal switching power supply: 100–240 V AC, 2.0 A, 50–60 Hz input; 24 V DC, 2.5 A, 60 W output |
| Weight | approx. 1.6 kg (3.6 lb) |
| Color | White |
| Operating Temperature | 0–40 °C, 25–85% RH non-condensing |
| Storage Temperature | −40–60 °C, 10–90% RH non-condensing |
| Warranty | Printer: 3 years (TSC EMEA); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first) |
| In the Box | TSC DH220LHC printer (203 dpi, LED indicators, no display, USB 2.0 + RS-232 + Ethernet + USB host, MFi Bluetooth, factory-fitted guillotine cutter), IEC 60601-1 medical-grade power supply (24 V DC, 60 W), power cord (EU Schuko plug), USB cable, quick start guide – labels NOT included |
Need a different display, media option or wireless option? All DH220LHC versions are listed above. Compare other models in our Desktop Label Printers collection or contact our team for volume pricing.
