TSC MH341T Industrial Label Printer (MH341T-A001-0302)

The TSC MH341T belongs to the MH241 Series – TSC's mainstream 4-inch industrial barcode label printer and the successor to the popular MH240. A die-cast print mechanism and base, a bi-fold metal cover with a large clear media window and a 4.3-inch colour touchscreen make it a dependable workhorse for production lines, warehouses and logistics centres. It prints in thermal transfer and direct thermal at 300 dpi and up to 305 mm/s, takes 203 mm (8-inch) label rolls and 600 m ribbons, and connects via USB, RS-232, Ethernet and two USB host ports as standard. This version, MH341T-A001-0302, is the Advanced model with the standard tear-off bar – peel-off, cutter and internal rewinder kits can be added later.

Key Features

• Industrial die-cast design – die-cast print mechanism and base, a bi-fold metal cover with a large clear media window and a full mechanism for fine adjustment.
• 4.3-inch colour touchscreen – intuitive multi-language menus with touch and six-button operation, plus LED status indicators.
• Thermal transfer and direct thermal – up to 305 mm/s at 300 dpi with a maximum print width of 104 mm.
• Large media capacity – label rolls up to 203 mm in diameter on 38/76 mm cores, media 20–114 mm wide; continuous, die-cut, black-mark, notched and fanfold media.
• 600 m ribbons – long ribbons on a 1-inch core mean fewer changes; ribbons coated inside or outside both work.
• Multi-connectivity – USB 2.0, RS-232, 10/100 Ethernet and two front USB host ports as standard; optional slot-in Wi-Fi 802.11ac + Bluetooth 4.2 module and GPIO interface for applicators.
• TSC Sense Care and remote management – self-diagnostic printhead care, near real-time status and warnings, plus SOTI Connect and TSC Console for remote fleet management.
• Easy replacement of other brands – TSPL-EZD with EPL, ZPL, ZPL II and DPL emulation runs existing label formats without changes.
• Upgrade options – regular, heavy-duty or care label cutter, peel-off kit, internal rewinder kit (5-inch OD), Wi-Fi + Bluetooth module, GPIO + parallel interface and KP-200 Plus keyboard display.

Ideal Applications

• Manufacturing – work-in-process, product marking, compliance and industrial-duty labels
• Transport and logistics – packing, order fulfilment, shipping and receiving, pallet labels
• Warehousing – inventory, location and asset labels
• Healthcare and pharma – specimen, pharmaceutical and asset tracking labels

All MH241 Versions

The highlighted row is the version you are currently viewing.

Technical Specifications

Which MH241 should you choose? 203 dpi is the fastest choice for barcodes and shipping labels, 300 dpi gives crisper small text and logos, and 600 dpi is made for micro labels and tiny 2D codes. Choose the Advanced (T) model with tear-off bar or the Premium (P) model with built-in internal rewinder. Compare other models in our Industrial Label Printers collection or contact our team for volume pricing.
