| Tootekood | U20F0C-P2CFRS-HF-R |
| Mudel | M3 Mobile UL20F – frozen model (−30 °C) of the UL20 ultra-rugged series |
| Operatsioonisüsteem | Android 9.0 (Pie) with Google Mobile Services (GMS) |
| Protsessor | Octa-core, 2.2 GHz |
| Mälu (RAM / Flash) | 4 GB RAM / 64 GB Flash |
| Ekraan | 5" Full HD (1920 × 1080), outdoor-viewable, Corning Gorilla Glass; heated, frost-free display |
| Puutepaneel | Capacitive multi-touch – finger, glove, wet operation and stylus |
| Klaviatuur | 28-key numeric keypad + 6 programmable side keys; frozen keypad for cold-store use |
| Skannimootor | Zebra SE4750 1D/2D imager; 25° angled scan head; heated scan window |
| Tagakaamera | 16 MP auto-focus with LED flash |
| Wi-Fi | Wi-Fi 5 – IEEE 802.11 a/b/g/n/ac/d/e/h/i/k/r/w, dual-band |
| Bluetooth | Bluetooth 4.1 LE, Class II |
| NFC | 13.56 MHz; ISO 14443 A/B, ISO 15693; peer-to-peer, card reader and card emulation |
| Mobiilne andmeside (WWAN) | Not available – Wi-Fi only (choose the UL20FX for 4G LTE) |
| GPS/GNSS | Not available |
| Kõne ja heli | Speaker, microphone, vibration; Bluetooth headset support |
| Pordid | USB 2.0 client (USB-C) and USB 2.0 host (USB-A) via the charging cradle; charging contacts on the device |
| Andurid | Light sensor, proximity sensor, accelerometer, gyroscope, magnetometer (eCompass) |
| Aku | 6700 mAh / 3.6 V Li-ion freezer battery designed for low temperatures (UL20-BATT-F67); hot-swappable |
| Aku tööaeg | Up to 10 hours (M3 user manual) |
| Laadimine | In a charging cradle (UL20-2CRD-CU0 / UL20-2CRD-EU0 with UL20-PWSP-2EU) or vehicle cradle – not included; fast charging, approx. 4–5 h from empty |
| Korpuse tüüp | Ultra-rugged keypad computer with 25° angled scan head |
| Mõõtmed | 88.7 × 244.75 × 46.19 mm (W × H × D) |
| Kaal | 530 g (2D scanner) |
| Kukkumiskindlus | 2 m to concrete (3 m with rubber boot) across the operating temperature range, MIL-STD-810G |
| Veeretuskindlus | 4,000 tumbles at 1 m (without boot) |
| Kaitseaste | IP67 |
| Töötemperatuur | −30 °C to 60 °C |
| Säilitustemperatuur | −40 °C to 80 °C |
| Õhuniiskus | Condensation-free thanks to internal heaters |
| Soojendus | Scan window heater and LCD heater, automatic (sensor-controlled) |
| Tarkvara ja haldus | M3 Mobile StartUp and ScanEmul; MDM support (e.g. SOTI MobiControl) |
| Värv | Black |
| Garantii | 12 months (M3 Mobile 1-year hardware warranty); 3- and 5-year M3 service packages available |
| Pakendi sisu | M3 Mobile UL20F mobile computer (U20F0C-P2CFRS-HF-R), 6700 mAh Li-ion freezer battery (UL20-BATT-F67), Google Mobile Services (GMS) licence preinstalled, quick start guide – charging cradle, power supply and hand strap NOT included (order separately) |
