TSC TE210 (99-065A301-U1LF00) on kompaktne 4-tolline lauaetiketiprinter termoülekande- ja otsetermiliseks printimiseks eraldusvõimega 203 dpi ja kiirusega kuni 152 mm/s (6 ips). See mahutab 127 mm etiketirulle ja suuri 300 m linte, kasutab TSPL-EZD keelt EPL-, ZPL- ja DPL-emulatsiooniga ning ühendub USB 2.0, RS-232, 10/100 Etherneti ja USB-hostpordi ning sisseehitatud Bluetooth 4.0 kaudu. Komplektis on toiteplokk, EL-pistikuga toitejuhe ja USB-kaabel – valmis printimiseks.
📦 Pakendi sisu – 99-065A301-U1LF00
- ✅ Etiketiprinter TSC TE210 – 203 dpi, USB 2.0, RS-232, Ethernet 10/100, USB host + Bluetooth 4.0
- ✅ Toiteplokk – väline universaalne toiteplokk, 100–240 V AC → 24 V DC, 60 W
- ✅ Toitejuhe – EL pistik (Schuko)
- ✅ USB-kaabel – USB 2.0 A–B – ühendage ja printige kohe
- ✅ Etiketivõlli komplekt – 1" etiketivõll, 2 kinnitusklambrit ja 2 × 1,5" südamikuadapterit
- ✅ Lindivõllid – 2 × 1" lindivõlli ja tühi 1" papist südamik 300 m lintide jaoks
- ✅ Windowsi draiverid ja etiketitarkvara – TSC draiver ja etiketitarkvara (CD või tasuta allalaadimine TSC veebilehelt)
- ✅ Paigaldusjuhend
- ❌ Termoülekandelint (ribbon) – EI kuulu komplekti – vajalik ainult termoülekandeprintimiseks – otsetermilised etiketid prinditakse ilma lindita
- ❌ Etiketid – EI kuulu komplekti – tellige oma kasutusotstarbele sobivad etiketid (vt ühilduvaid etikette allpool)
- ❌ Etherneti (LAN) kaabel – EI kuulu komplekti – sobib mis tahes tavaline RJ45 võrgukaabel
✅ Valmis printimiseks: toiteplokk, toitejuhe ja USB-kaabel on komplektis – vaja on vaid etikette (ja termoülekandeprintimiseks linti).
💡 Kasulikud lisad: lindid, mille värvikiht on VÄLJASPOOL, nt TSC 8050-SWX (P159049-001) (110 mm × 300 m, 1" südamik); väline rullihoidik TSC OP-COM-0002 suurtele 214 mm (8,4") rullidele 3" südamikul; giljotiinlõikur TSC CUT-TE200-0001 (täis-/osaline lõige) või etiketieraldaja TSC PEL-TE200-0001; klaviatuur TSC KP-200 Plus iseseisvaks printimiseks ilma arvutita.
Peamised omadused
- Termoülekanne ja otsetermiline printimine 203 dpi juures – kuni 152 mm/s (6 ips), max prindilaius 108 mm
- 300 m lindid 1" südamikul (värvikiht väljas) – harvem lindivahetus; sobivad ka 72–110 m lindid 0,5" südamikul, laius 40–110 mm
- 127 mm (5") etiketirullid 25,4–38 mm südamikul, meediumi laius 20–112 mm; leporello-söötmine ja valikuline väline rullihoidik 214 mm rullidele
- 32-bitine RISC-protsessor, 64 MB SDRAM ja 128 MB Flash, reaalajakell ja sisseehitatud helisignaal
- TSPL-EZD püsivara EPL-, ZPL/ZPL II- ja DPL-emulatsiooniga – asendab olemasolevad etiketiprinterid ilma ümberseadistamiseta
- USB 2.0, RS-232, 10/100 Ethernet ja sisseehitatud Bluetooth 4.0 ning USB-hostport skanneri või klaviatuuri jaoks
- Läbivalgusega vaheandur, reguleeritav mustamärgiandur, lindi lõpu ja avatud prindipea andurid
- Lisavalikud: etiketieraldaja ja giljotiinlõikur (täis-/osaline lõige); KP-200 Plus klaviatuur iseseisvaks printimiseks
- Lihtne prindipea ja survevõlli vahetus; TSC 3-aastane garantii EMEA piirkonnas
Sobib ideaalselt
- Saatmis- ja vastuvõtuetiketid e-kaubandusele, pakiteenustele ja postile
- Ladu ja tootmine – toote-, pooltoote-, juhend- ja nõuetele vastavuse etiketid
- Jaekaubandus – hinnasildid, riiulietiketid ja ehtesildid
- Tervishoid – patsiendi tuvastus-, apteegi- ja proovietiketid
- Väikekontor ja kodukontor – kaustaetiketid, toote tähistamine ja aadressietiketid
Kõik TE200 seeria versioonid
Esiletõstetud rida on praegu vaadatav versioon.
| Tootekood | Mudel | Eraldusvõime | Liidesed | Juhtmevaba | Toitejuhe | |
|---|---|---|---|---|---|---|
| 99-065A101-00LF00 | TE200 | 203 dpi | USB | — | EL (Schuko) | Vaata toodet |
| 99-065A10F-00LF00 | TE200 | 203 dpi | USB | — | UK | Vaata toodet |
| 99-065A101-U1LF00 | TE200 | 203 dpi | USB | Bluetooth 4.0 | EL (Schuko) | Vaata toodet |
| 99-065A301-00LF00 | TE210 | 203 dpi | USB, RS-232, Ethernet, USB host | — | EL (Schuko) | Vaata toodet |
| 99-065A30D-00LF00 | TE210 | 203 dpi | USB, RS-232, Ethernet, USB host | — | UK | Vaata toodet |
| 99-065A301-U1LF00 (see versioon) | TE210 | 203 dpi | USB, RS-232, Ethernet, USB host | Bluetooth 4.0 | EL (Schuko) | Vaatate |
| 99-065A301-S1LF00 | TE210 | 203 dpi | USB, RS-232, Ethernet, USB host | Wi-Fi | EL (Schuko) | Vaata toodet |
| 99-065A701-00LF00 | TE300 | 300 dpi | USB | — | EL (Schuko) | Vaata toodet |
| 99-065A701-U1LF00 | TE300 | 300 dpi | USB | Bluetooth 4.0 | EL (Schuko) | Vaata toodet |
| 99-065A901-00LF00 | TE310 | 300 dpi | USB, RS-232, Ethernet, USB host | — | EL (Schuko) | Vaata toodet |
Tehniline spetsifikatsioon
| Tootekood | 99-065A301-U1LF00 |
|---|---|
| Mudel | TSC TE210 (TE200 Series) |
| Printeri tüüp | 4-inch desktop thermal transfer label printer |
| Printimismeetod | Thermal transfer and direct thermal |
| Eraldusvõime | 203 dpi (8 dots/mm) |
| Printimiskiirus | Up to 152 mm/s (6 ips) |
| Max prindilaius | 108 mm (4.25") |
| Max prindipikkus | 25,400 mm (1,000") |
| Meediumi laius | 20–112 mm (0.8"–4.4") |
| Meediumi paksus | 0.06–0.19 mm (2.36–7.48 mil) |
| Rulli läbimõõt | 127 mm (5") OD inside the printer; up to 214 mm (8.4") OD with the optional external roll mount |
| Südamiku läbimõõt | 25.4–38 mm (1"–1.5"); 76.2 mm (3") with the optional external roll mount |
| Meediumi tüübid | Continuous, die-cut, black mark, fanfold, notched (outside wound) |
| Andurid | Transmissive gap sensor, reflective black-mark sensor (position adjustable), ribbon-end sensor, head-open sensor |
| Lint (ribbon) | 300 m on 1" (25.4 mm) core, max. OD 67 mm; or 72–110 m on 0.5" (12.7 mm) core, max. OD 40 mm; width 40–110 mm; ink coated OUTSIDE only |
| Liidesed | USB 2.0, RS-232 serial, internal Ethernet 10/100 Mbps, USB host (for scanner or PC keyboard) |
| Juhtmevaba ühendus | Internal Bluetooth 4.0 (factory-installed) |
| Protsessor | 32-bit RISC CPU (400 MHz) |
| Mälu | 64 MB SDRAM, 128 MB Flash |
| Reaalajakell | Standard (plus built-in buzzer) |
| Printerikeeled | TSPL-EZD (EPL, ZPL, ZPL II and DPL compatible) |
| Fondid / märgistikud | 8 alphanumeric bitmap fonts; Monotype true-type engine with CG Triumvirate Bold Condensed scalable font; 0/90/180/270° rotation |
| Ribakoodid | 1D: Code 128 (subsets A/B/C, UCC), EAN-128, Interleaved 2 of 5, Code 39, Code 93, EAN-13, EAN-8, UPC-A, UPC-E, Codabar, ITF-14, MSI, Plessey, Code 11, Telepen, Postnet, Planet, Code 49, Deutsche Post Identcode/Leitcode, LOGMARS; 2D: GS1 DataBar, GS1 DataMatrix, MaxiCode, Aztec, PDF417, Micro PDF417, QR Code |
| Ekraan | No LCD – 1 three-colour status LED (green/amber/red), feed/pause button, power switch |
| Meediumi käsitlemine | Tear-off (standard); optional peel-off module and guillotine cutter (full/partial cut) |
| Lisavarustus | External roll mount (214 mm OD, 3" core); KP-200 Plus keyboard; KU-007 Plus smart keyboard; external Bluetooth module (serial) |
| Draiverid ja tarkvara | Windows drivers and TSC labeling software (CD / free download), TSC Console |
| Toide | External universal switching power supply: 100–240 V AC, 50–60 Hz input; 24 V DC, 2.5 A, 60 W output |
| Mõõtmed (L × S × K) | 204 × 280 × 164 mm (W × D × H) |
| Kaal | 2.5 kg |
| Värv | Black |
| Töötemperatuur | 5–40 °C, 25–85% RH non-condensing |
| Hoiutemperatuur | −40–60 °C, 10–90% RH non-condensing |
| Sertifikaadid | FCC, CE, UL/cUL, TÜV, CCC, EAC, BIS, KC; ENERGY STAR; RoHS, REACH, WEEE |
| Garantii | Printer: 3 years (TSC EMEA, purchases from 1 June 2024); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first) |
| Pakendi sisu | TSC TE210 printer (203 dpi, USB 2.0, RS-232, Ethernet 10/100, USB host + Bluetooth 4.0), external power supply (24 V DC, 60 W), power cord (EU Schuko plug), USB cable, 1" label spindle with 2 fixing tabs and 2 × 1.5" core adapters, 2 × 1" ribbon spindles + empty 1" ribbon core, Windows labeling software/drivers (CD or download), quick start guide – ribbon and labels NOT included |
Vajate teistsugust liidest, eraldusvõimet või pistikut? Kõik TE200 seeria versioonid on toodud ülal. Võrrelge teisi mudeleid meie kollektsioonis Lauaetiketiprinterid või küsige meie meeskonnalt hulgihinda.
