The Datalogic Magellan 3550HSi is a high-performance horizontal in-counter barcode scanner for busy, high-volume checkouts. Installed flush with the counter, its 1.3 MP digital imager matches the speed and large field of view of laser scanners while also reading 2D codes – from paper labels and phone screens alike – with both fast sweep and presentation scanning. Every unit has multiple interfaces, a powered USB port for the optional Customer Service Scanner and Checkpoint/Sensormatic EAS compatibility, and it comes with a 3-year Datalogic warranty. This version, M3550-010200, is supplied without a platter (the top with the scan window) and without accessories – intended for replacing the scanner in an existing Magellan 35xxHSi installation and reusing its top. Interface cable, counter mount, power supply and power cord are not included.
📦 What's in the box – M3550-010200
- ✅ Datalogic Magellan 3550HSi scanner – in-counter 1D/2D imager, supplied without platter
- ❌ Platter (top with scan window) – not included
- ❌ Interface cable – not included
- ❌ Counter mount – not included
- ❌ Power supply and power cord – not included – required for USB Type A and RS-232 connections; not needed with the OEM (IBM) powered USB cable on IBM/Toshiba POS terminals
⚠️ No platter included: this scanner is supplied without its top (scan window) and cannot be used on its own. Reuse the top of your existing Magellan 35xxHSi or order the Datalogic Tin Oxide Top 90ACC0302. Need a complete scanner? Choose M3551-010210 (sapphire glass platter).
⚠️ No interface cable and no power supply are included. For a standard PC or POS USB port, order the Datalogic USB cable 90A052292 (Type A, 4.5 m) together with the Datalogic 12 V / 18 W power supply 90ACC0358 and a power cord (EU 6003-0940). For IBM/Toshiba POS terminals, the Datalogic OEM (IBM) USB cable 90A052311 (4.6 m) is enough – the terminal powers the scanner. For a serial port, order the Datalogic RS-232 cable 90A052121 (9-pin, 4.5 m) plus the power supply. Prefer a ready-to-use kit? Choose M3551-010210-07604 – USB cable, power supply, EU power cord and counter mount included.
💡 Installing the scanner in a new counter cut-out? Choose M3550-010210 (the same version with the Standard Counter Mount) or add the Datalogic Split Mount 90ACC0355.
Key Features
- High-performance digital imaging – a 1.3 MP (1280 × 1024) sensor processes up to 39 million pixels per second and matches the speed and large field of view of laser scanners, supporting both fast sweep and presentation scanning; even truncated, out-of-spec and poorly printed codes are read with ease.
- 1D, 2D and mobile codes – reads all standard 1D codes, GS1 DataBar, PDF417, Data Matrix, QR and Aztec codes from paper and phone screens; support for Digimarc digital watermarks is available as an option.
- Multiple interfaces in every unit – OEM (IBM) USB, RS-232, USB Keyboard and USB COM, selected by the cable; on IBM/Toshiba POS terminals the scanner is powered through the OEM (IBM) USB cable, on a standard USB or RS-232 port through the 12 V power supply.
- Made for high-volume checkouts – compact 15.2 × 15.2 cm top and only 8.7 cm depth below the counter; cables, mounts and tops are shared with the Magellan 35xxHSi series, and the version without a platter lets you reuse the top of an existing scanner.
- Customer Service Scanner ready – a powered USB auxiliary port for the optional Magellan Customer Service Scanner (CSS), so shoppers can scan phone screens, coupons and loyalty cards while the cashier keeps scanning items.
- Loss prevention – compatible with Checkpoint Systems and Tyco Sensormatic EAS systems.
- Software-driven and easy to manage – flexible, upgradeable firmware, image capture (BMP, JPEG), micro SD card slot, diagnostics reporting, host download and Magellan ULE scripting; remote management via OPOS, JavaPOS, Toshiba Remote Management (IBM Systems Director) and Wavelink Avalanche.
- Comfortable and reliable – subtle, adaptive illumination is easy on the eyes, solid-state electronics work silently, and the speaker plays adjustable tones or custom .wav files; IP52 sealing, a 3-year Datalogic factory warranty and optional EASEOFCARE service plans.
Ideal Applications
- High-volume supermarket and grocery checkout lanes (installed in the counter)
- Convenience stores, pharmacies and specialty retail
- Self-checkouts and kiosks
- Mobile coupons, loyalty cards and mobile marketing
- Age verification by reading 2D codes on ID documents
All Magellan 3550HSi Versions
The highlighted row is the version you are currently viewing.
| Part Number | Platter | Cable | Counter Mount | |
|---|---|---|---|---|
| M3550-010200 (this version) | ❌ No platter | ❌ Not included | ❌ Not included | Viewing |
| M3550-010210 | ❌ No platter | ❌ Not included | Standard Counter Mount | View product |
| M3551-010210 | Sapphire glass | ❌ Not included | Standard Counter Mount | View product |
| M3551-010210-07604 | Sapphire glass | USB Type A (4.5 m) + power supply + EU cord | Standard Counter Mount | View product |
Technical Specifications
| Part Number | M3550-010200 |
|---|---|
| Model | Datalogic Magellan 3550HSi (Magellan 35xxHSi series) |
| Scanner Type | Corded horizontal in-counter scanner (high-performance digital imager, reads 1D and 2D barcodes) |
| Image Sensor | 1280 × 1024 pixels (1.3 MP); read rate up to 39 million pixels per second |
| Light Source | Multiple diffused LEDs, orientation and wavelength optimised for eye comfort |
| Read Height | 10.2 cm / 4.0 in |
| Maximum Resolution | 0.127 mm (5 mil) |
| Minimum Print Contrast | 25% |
| 1D Symbologies | All standard 1D codes incl. GS1 DataBar linear codes (auto-discrimination) |
| 2D Symbologies | Aztec Code, Data Matrix (ECC200 only), MaxiCode, QR Code |
| Stacked / Composite Codes | GS1 DataBar Composites, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MicroPDF417, PDF417 |
| Digital Watermark | Optional support for Digimarc Barcodes / GS1 DW Code (not part of the default configuration) |
| Image Capture | Yes – BMP, JPEG |
| Host Interfaces | Multi-interface in every unit: OEM (IBM) USB, RS-232, USB Keyboard, USB COM – the interface depends on the cable used (cable not included – order separately) |
| Auxiliary Port | Powered USB Type A (USB COM), e.g. for the optional Magellan Customer Service Scanner (CSS) with omni-mount |
| Reading Indicators | Audio speaker with adjustable tone and volume (supports .wav files); Good Read LED; Good Transmission indicator |
| EAS Compatibility | Checkpoint Systems: integrated EAS hardware works with Counterpoint IX and Evolve D11 (optional feature); Sensormatic: good-read acknowledgement |
| Platter (Scan Window) | Not included – supplied without platter (top with scan window); reuse the top of an existing Magellan 35xxHSi or order Tin Oxide Top 90ACC0302 |
| Counter Mount | Not included – optional: Standard Counter Mount 11-0027, Counter Mount with HS1250 Fill Kit 11-0178, Split Mount 90ACC0355 |
| Dimensions | 15.2 × 15.2 cm (top); depth below counter 8.7 cm |
| Weight | 0.98 kg |
| Input Voltage | AC input 100–240 VAC, 50–60 Hz via 12 V power supply – power supply not included: order the 12 V / 18 W power supply 90ACC0358 + power cord for USB Type A and RS-232; with OEM (IBM) powered USB the scanner is powered by the IBM/Toshiba POS terminal |
| Power Consumption | Max. 4.0 W; nominal 3.0 W; sleep mode 2.8 W |
| Environmental Sealing | IP52 |
| Electrostatic Discharge | 25 kV (air discharge) |
| Ambient Light Immunity | 0–86,100 lux |
| Operating Temperature | 0 °C to 40 °C |
| Storage Temperature | −40 °C to 70 °C |
| Humidity | 5–95% RH, non-condensing |
| Software & Management | Magellan Scanalyzer configuration software; OPOS / JavaPOS utilities; remote management via OPOS, JavaPOS, Toshiba Remote Management (IBM Systems Director) and Wavelink Avalanche; diagnostic reporting, host download, Magellan ULE scripting; micro SD card slot |
| Warranty | 36 months |
| In the Box | Magellan 3550HSi scanner WITHOUT platter (top with scan window not included) – platter, interface cable, counter mount, power supply and power cord NOT included (order separately) |
Not sure which version you need? All Magellan 3550HSi versions contain the same high-performance in-counter imager. M3551-… versions have the highly scratch-resistant sapphire glass platter, while M3550-… versions come without a platter so you can reuse the top of your existing Magellan 35xxHSi. For a new installation, choose a version with the Standard Counter Mount or the complete USB kit M3551-010210-07604 with cable, power supply and EU power cord. Looking for a more economical scanner that runs from a single USB port without a power supply? See the Magellan 3510HSi. Compare other models in our In-Counter Barcode Scanners collection or contact our team for volume pricing.
Available Versions
M3550-010200
Selected
No platter (top not included)
Not included: interface cable, counter mount, power supply, power cord
built-in scanner, retail, 2D, imager, micro SD-Slot, multi-interface (RS232, USB, IBM), IP52, order separately: interface cable, power supply unit, power cable
557,27 €Out of Stock
M3550-010210
No platter (top not included)
Includes: Standard Counter Mount
Not included: interface cable, power supply, power cord
built-in scanner, retail, 2D, imager, micro SD-Slot, multi-interface (RS232, USB, IBM), IP52, mounting frame, order separately: interface cable, power supply unit, power cable
M3551-010210
Sapphire glass platter
Includes: Standard Counter Mount
Not included: interface cable, power supply, power cord
built-in scanner, retail, 2D, imager, sapphire glass, micro SD-Slot, multi-interface (RS232, USB, IBM), IP52, order separately: interface cable, power supply unit
M3551-010210-07604
Sapphire glass platter
Includes: USB cable (4.5 m), 12 V power supply + EU power cord, Standard Counter Mount
built-in scanner, retail, 2D, imager, sapphire glass, micro SD-Slot, multi-interface (RS232, USB, IBM), IP52, incl.: cable (USB, 4.5 m), power supply unit, power cable (EU), mounting frame
